Overall Vehicle Parameters
|
|
Length × Width × Height (mm)
|
9090×2530×3530
|
14720×2550×4000
|
-
|
|
Total Weight (kg)
|
21000
|
46000
|
-
|
|
Boom & Outrigger Parameters
|
|
Vertical Reach of Boom (m)
|
32.2
|
62.1
|
61.2
|
|
Horizontal Reach of Boom (m)
|
28.2
|
55.4
|
56
|
|
Vertical Depth of Boom (m)
|
21.8
|
44.2+3(hose)
|
44.3
|
|
Minimum Deployment Height (m)
|
-
|
15.8
|
-
|
|
Slewing Angle of Turntable (°)
|
360°
|
±360°
|
±270°
|
|
Front Outrigger Span (mm)
|
5760
|
9780
|
12250
|
|
Rear Outrigger Span (mm)
|
6605
|
13490
|
12960
|
|
Side Outrigger Span (mm)
|
6149
|
-
|
11840
|
|
Conveying System Parameters
|
|
Theoretical Concrete Output (m³/h)
|
120
|
180
|
180
|
|
Theoretical Conveying Pressure (MPa)
|
10
|
12
|
11.3
|
|
Theoretical Pumping Cycles (cycles/min)
|
-
|
27±1
|
26
|
|
Hydraulic Oil Tank Capacity (L)
|
320
|
450+450
|
201+338
|
|
Chassis Parameters
|
|
Chassis Brand
|
SANY
|
SANY
|
-
|
|
Max. Engine Net Power (kW/rpm)
|
191/2200
|
274/1900
|
-
|
|
Fuel Tank Capacity (L)
|
300
|
400
|
-
|
|
Displacement (L)
|
5.132
|
8.7
|
-
|
|
Max. Travel Speed (km/h)
|
85
|
90
|
-
|
