Product Introduction

Product documentation

Brand	SANY		XCMG
Model	SY135C	SY125C	XE155GA	XE75G
Parameters
Overall Machine Weight (kg)	13500	12500	14600	7680
Rated Power (kW/rpm)	86kW/2200rpm	89kW/2200rpm	96/2200	36.8/2200
Engine	Isuzu 4JJ1	Cummins QSF4.5	F4.5CS4129	Weichai WP3.2
Bucket Capacity (m³)	0.6	0.54	0.32~0.72	0.32
Maximum Torque (Nm/rpm)	375Nm/1800rpm	500Nm/(1300-1700rpm)	570Nm/1300rpm	240Nm/1200-1400rpm
Engine Displacement (L)	2.999	4.5	4.5	3.17
Main Performance
Travel Speed (High/Low) (km/h)	5.5/3.5	5.5/3.5	5.3/3.0	4.3/2.5
Swing Speed (rpm)	12	12	11	11
Gradeability (°)	70%(35°)	70%(35°)	≤70%(35°)	70%(35°)
Ground Pressure (kPa)	41.7	41.6	37	33.5
Bucket Digging Force (kN)	103	100	107	57
Arm Digging Force (kN)	67	62	74	38
Fluid Capacities
Fuel Tank Capacity (L)	280	280	240	170
Hydraulic Tank (L)	200	150	95	76
Undercarriage
Number of Track Shoes per Side	44	41	-	-
Carrier Wheel on Each Side	1	1	-	-
Thrust Wheel on Each Side	7	7	-	-
Width of Track Pad (mm)	500	500	-	-
