Parameters
|
|
Engine Model
|
Kubota D1803
|
Deutz D07S4
|
-
|
-
|
|
Rated Power/Speed (kW/rpm)
|
24/2600
|
180
|
103
|
140
|
|
Max Operating Weight (kg)
|
2920
|
30000
|
14000
|
22000
|
|
Front Axle Weight (kg)
|
1440
|
19000
|
-
|
-
|
|
Rear Axle Weight (kg)
|
1480
|
11000
|
-
|
-
|
|
Static Linear Load of Drum (N/cm)
|
-
|
858
|
329
|
516
|
|
Vibration Frequency (Hz)
|
55/67
|
27/32
|
28/33
|
28/33
|
|
Amplitude (mm)
|
0.5
|
2.05/1.03
|
-
|
-
|
|
Exciting Force (kN)
|
28/42
|
435/315
|
274/190
|
374/290
|
|
Drum Diameter (mm)
|
700/1200
|
1700
|
-
|
-
|
|
Drum Width (mm)
|
-
|
2170
|
2130
|
2130/35
|
|
Drum Shell Thickness (mm)
|
-
|
40
|
-
|
-
|
|
Travel Speed (km/h)
|
-
|
0~7.9
|
-
|
-
|
|
Gradeability (Vibration/No Vibration) (%)
|
30/40
|
40
|
35
|
35
|
|
Min Ground Clearance (mm)
|
-
|
470
|
-
|
-
|
|
Wheelbase (mm)
|
-
|
3518
|
-
|
-
|
|
Min Turning Outer Diameter (mm)
|
-
|
13640
|
-
|
-
|
|
Tire Size
|
-
|
23.5-25-16
|
-
|
-
|
|
Battery (V×Ah)
|
-
|
24×120
|
-
|
-
|
|
Engine Brand
|
Kubota
|
-
|
Shangchai
|
Shangchai
|
|
Emission Standard
|
China IV
|
China IV
|
China IV
|
-
|
|
Fuel Tank Capacity (L)
|
50
|
300
|
-
|
-
|
|
Hydraulic Tank Capacity (L)
|
-
|
100
|
-
|
-
|
